Field Hospital Tent Introduce

نبذة عن المشروع

The spread of the epidemic has led to insufficient hospitals. Expansion hospitals and solving medical problems have become the primary issues. Liri Rescue Tent can produce prefabricated aluminum alloy pipes at the factory in advance and transport them to the site. They can quickly deploy the solutions of medical tents, field hospitals and square cabin hospitals. The hospitals can be built and put into use in 1-3 days at the earliest, improving the speed of medical rescue.

The quickly assembled rescue Field Hospital Tent can be freely divided inside to become a separate room. And it can also provide a collective isolation resting area to ensure the safety and rest of medical staff.

Medical Tents Series Specifications
عرض الامتدادارتفاع الحافةارتفاع الحافةمسافة الخليجالملف الشخصي الرئيسي
3m2.6m3.16m3m100x48x3.0mm (4 - channel)
4 أمتار2.6m3.35m3m100x48x3.0mm (4 - channel)
5 أمتار2.6m3.52m3m100x48x3.0mm (4 - channel)
6 أمتار2.6m3.71m3m100x48x3.0mm (4 - channel)
8m2.6m4.05m3m100x48x3.0mm (4 - channel)
9m2.6m4.24m3m100x48x3.0mm (4 - channel)
10 أمتار2.6m4.4m3m100x48x3.0mm (4 - channel)
12 مترًا
2.6m4.76m3m100x48x3.0mm (4 - channel)
مقال مميز

دعامات الإطار: ألومنيوم مبثوق ومضغوط بقوة من النوع 6061/T6(15HW)

غطاء من القماش: نسيج بوليستر عالي الجودة مطلي بطبقتين من مادة PVC؛ مقاوم للماء وفقًا لمعيار 100%؛ مقاوم للهب وفقًا لمعايير DIN4102 B1 وM2 وCFM؛ مقاوم للأشعة فوق البنفسجية، ومقاوم للتمزق، وله قدرة على التنظيف الذاتي، إلخ

الموصل: فولاذ قوي مجلفن بالغمس الساخن

نطاق درجات الحرارة المسموح به: -30 درجة مئوية إلى +70 درجة مئوية

حمل الرياح: بحد أقصى 100 كم/ساعة

حمل الثلج: 75 كجم/م² (لا يمكن أن يثبت الثلج في حالة استخدام تصميم بسقف ذي ميل حاد)

سهل التجميع والتفكيك

لا يوجد عمود بالداخل، المساحة الداخلية المتاحة 100%
